    service We offer customers a variety of individual resistor solutions. In-house test laboratories give us the ability to conduct empirical testing very quickly. Not only solutions in thick film technology but also specific resistors in different stainless steel models are custom made for the respective applications. Individual low-volume series are also welcome – so that you receive resistors that contribute ideally to your product´s and project´s success.

  • Series JEP High Pulse Absorption Resistors

    Series JEP High Pulse Absorption Resistors

    Derating Dimensions in millimeters Specifications Resistance ranges 200Ω -1GΩ Resistance Tolerance  ±0.5%~± 10% Temperature Coefficient  ±25PPM/℃~±80PPM/℃(25℃~105℃) On special request Max. Operating Temperature 225℃ Lead Material  O.F.H.C. Copper nickel plated On special request for different Voltage and Size Ordering Information    Type    ohmic  Value    TOL   JCP65     60K    1%  25PPM

  • Series UPR/UPSC High Precision Metal Film Resistors

    Series UPR/UPSC High Precision Metal Film Resis...

    Derating Dimensions Dimensions in millimeter (inches) UPSC UPR A 7.50±0.20 10.50±0.30 (0.295±0.008) (0.413±0.012) B 8.50±0.20 9.00±0.30 (0.335±0.008) (0.354±0.012) C 2.50±0.20 4.00±0.30 (0.098±0.008) (0.157±0.012) D 0.63±0.20 0.63±0.0.05 (0.025±0.008) (0.025±0.002) E 3.81±0.38 7.62±0.38 (0.150±0.015) (0.300±0.015) F 25±1 18±5 (0.98±0.04) (0.71±0.196) Technical and standard ele...

  • Series EE High Precision Metal Film Resistors

    Series EE High Precision Metal Film Resistors

    Derating Derating (thermal resist.) SUP600: 8.47W/K (0.12 K/W) Power rating: 600 W at 85°C bottom case temperature This value is only applicable when using a thermal conduction to the heat sink Rth-cs<0.025K/W. This value can be obtained by using a thermal transfer compound with a heat conductivity of at least 1 W/mK. The flatness of the cooling plate must be better than 0.05 mm overall. Surface roughness should not exceed 6.4 μm. Dimensions in millimeters Specifications Resistance r...

  • Series PBA Precision Resistor

    Series PBA Precision Resistor

    Derating Derating (thermal resist.) SUP300: 4.24W/K (0.24 K/W) Power rating: 300 W at 85°C bottom case temperature This value is only applicable when using a thermal conduction to the heat sink Rth-cs<0.025K/W. This value can be obtained by using a thermal transfer compound with a heat conductivity of at least 1 W/mK. The flatness of the cooling plate must be better than 0.05 mm overall. Surface roughness should not exceed 6.4 μm. Dimensions in millimeters Specifications Resistance r...

  • Series MCP Resistor

    Series MCP Resistor

    Derating Dimensions in millimeters Technical and standard electrical specifications Type Wattage 25°C Max. kV Dimensions in millimeters (inches) A(±0.50/±0.02) B (±0.50/±0.02) C(±0.50/±0.02) MCP05 0.5 3000 12.90/0.51 3.40/0.13 10.20/0.40 MCP07 0.65 4500 17.15/0.68 3.40/0.13 15.24/0.60 MCP12 1.20 5000 20.00/0.78 5.08/0.20 17.78/0.70 MCP16 1.60 8000 25.60/1.01 5.30/0.21 22.90/0.90 MCP30 3.00 9000 38.30/1.51...

  • Series JCP Resistor for Electronic Transformer

    Series JCP Resistor for Electronic Transformer

    Derating Dimensions in millimeters Technical and standard electrical specifications Type Wattage  (W) Max.Voltage  (KV) Resistance ranges (Ω ) Dimensions in millimeters (inches) A  (±1.00/±0.04) B  (±1.00 /±0.04) JCP65/15 25 25 100- 1G 65.00/2.56 16.00/0.63 JCP80/15 30 35 100- 1G 80.00/3. 15 16.00/0.63 JCP100/15 40 40 100- 1G 100.00/3.94 16.00/0.63 JCP130/15 45 50 100- 1G 130.00/5.12 16.00/0.63 JCP160/15 50 ...

  • Series SHV Resistor

    Series SHV Resistor

    Derating Derating (thermal resist.) LXP100 /LXP100 L: 0.66 W/K (1.5 K/W) Without a heat sink, when in open air at 25°C,the LXP100 /LXP100 L is rated for 3 W. Derating for temperature above 25°C is 0.023 W/K. Case temperature must be used for definition of the applied power limit. Case temperature measurement must be done with a thermocouple contacting the center of the component mounted on the designed heat sink. Thermal grease should be applied properly. This value is only applicable when u...
